2 Post Car Hoist | 5 Ton - Wireless - Independent Columns

Name: 2 Post Car Hoist | 5 Ton - Wireless - Independent Columns
Brand: Tufflift
SKU: E25
Price: 9900.00 AUD
Availability: OutOfStock

2 Post Car Hoist | 5 Ton - Wireless - Independent Columns

SKU:E25

$9,900.00 AUD inc. GST

~~$0.00 AUD~~ $9,900.00 AUD inc. GST

Sale Sold out

Taxes included. Shipping calculated at checkout.

Choose a Power Supply

Included with your Tufflift: RRP $480.80 AUD

The Tufflift E25 is a 5 Ton car hoist with a 5000KG capacity. With a 1.9m lifting height and full electronic controls, it delivers versatile and reliable performance, available in 240V or 3-phase power.

Features

5000KG Safe Working Limit
Lifting height of 1.9m
Overall height of 2.91m tall
Combines base plate and clear floor design
Full electronic controls
Aluminium power unit
Available in 240V or 3 phase power
Independent column
No cables or hoses on the floor
Combination screw pads plus 4WD adapter
Durable powder coating
Door protection pads

Includes

Hydraulic oil
Combination screw pads plus 4WD adapter

Safety

24V controls with isolation switch
Pre-set hydraulic pressure and ram limit switch
Rubber protected height limit switch bar
Arm locks
Anti-surge valve

Specifications

Capacity: 5000KG

Minimum Concrete Requirement: 150mm

Recommended Ceiling Height: 3.5m

Lock Release: Electric

Power: 240v: 2.2kw 16amps | 3 Phase: 3.5kw 9amps

Lifting Height: 1900 mm

Lifting Height with Adapters: 2060mm

Minimum Pad Height: 110mm

Overall Hoist Height: 2912 mm

Overall Hoist Width: 4028mm

Drive Through Clearance: 2970mm

Width Between Columns (body): 3342mm

Lifting Time:240v: 50-55sec | 3 Phase: 35-40sec

Arm Design: Asymmetric

Freight Dimensions:
L 2860mm W 650mm H 940mm W 667KG

Warranty

We offer a comprehensive warranty on the E25, covering 5 years on the structure and 2 year on electrical, mechanical, and hydraulic components.

This warranty includes both parts and labour, ensuring that your 2 post clear floor hoist remains reliable and fully supported, giving you peace of mind throughout its use.
