Tufflift

2 Post Car Hoist - 4.5 Ton Base Plate

Name: 2 Post Car Hoist - 4.5 Ton Base Plate
Brand: Tufflift
SKU: EE-F10
Price: 3890.00 AUD
Availability: InStock

SKU:EE-F10

$3,890.00 AUD

Sale

Choose a Power Supply

Included with your Tufflift: RRP $629.30 AUD

Introducing the Tufflift EE-F10, a 4.5 Ton base plate car hoist with a 4500KG capacity and 1.80m lifting height (plus screw pad adjustment). Featuring a single lock release, durable powder coating, and door protection pads, it’s available in 240V or 3-phase power. Engineer-certified and Worksafe registered, it’s built for robust and reliable lifting in any workshop.

Features

4500KG Safe Working Limit
Lifting height of 1.80m (plus screw pad adjustment)
Base Plate design
Single lock release
Available in 240V or 3 Phase power
Durable Powder Coating
Door protection pads

Includes

Hydraulic oil
Screw Pads
Anchor bolts
Engineer Certified
Design Registered with Worksafe

Options:

Low Profile Arm
Tyre Holder Adapter
Zappi 7kw Untethered EV Charge Station

Safety

Anti-surge valve
Automatic mechanical carriage locks
Automatic mechanical arm locks

Specifications

Capacity: 4500 Kg

Minimum Concrete Requirement: 150mm

Recommended Ceiling Height: 3.25m

Lock Release: Single Point

Power: 240v: 2.2kw 16 amps | 3 Phase: 3.5kw 9 amps

Lifting Height: 1800 – 1870mm

Lifting Height With Adapters: 1870mm

Minimum Pad Height: 100mm

Overall Height: 2827mm

Overall Width (without motor): 3420mm

Drive Through Clearance: 2558mm

Lifting Time:240v: 50-55sec | 3 Phase: 35-40sec

Lowering Time: 55 seconds

Arm design: Asymmetric

Freight Dimensions:
L 2900mm W 560mm H 1100mm W 730KG

Warranty

We offer a comprehensive warranty on the EE-F10, covering 5 years on the structure and 1 year on electrical, mechanical, and hydraulic components.

This warranty includes both parts and labour, ensuring that your 2 base plate floor hoist remains reliable and fully supported, giving you peace of mind throughout its use.
