Measurements and colour are correct at the time of publishing, however are subject to change. If these are crucial to your facility or vehicle requirements it is essential for you to discuss your particular requirements with your Tufflift advisor prior to purchasing your new hoist.

Tufflift

2 Post Car Hoist - 4 Ton Clear Floor

Name: 2 Post Car Hoist - 4 Ton Clear Floor
Brand: Tufflift
SKU: EE-C9
Price: 3690.00 AUD
Availability: InStock

SKU:EE-C9

$3,690.00 AUD

Sale

Choose a Power Supply

Included with your Tufflift: RRP $464.30 AUD

Introducing the Tufflift EE-C9, a 4 Ton clear floor car hoist with a 4000KG capacity and a 1.90m lifting height (plus adapter and screw pad adjustments). Designed with a single lock release, durable powder coating, and door protection pads, it’s available in 240V or 3-phase power. Engineer-certified and Worksafe registered, it’s a reliable choice for professional lifting needs.

Features

4000KG Safe Working Limit
Lifting height of 1.90m (plus adapters and screw pad adjustment)
Clear floor design
Single lock release
Available in 240V or 3 Phase power
Durable Powder Coating
Door protection pads

Includes

Hydraulic oil
Combination screw pads
4 x 4WD adapters
Anchor bolts
Engineer Certified
Design Registered with Worksafe

Options:

Low Profile Arm
Tyre Holder Adapter
Zappi 7kw Untethered EV Charge Station

Safety

Anti-surge valve
Automatic mechanical carriage locks
Automatic mechanical arm locks
Standard column curtain

Specifications

Capacity: 4000 kg

Minimum Concrete Requirement: 115mm

Recommended Ceiling Height: 4.2m

Lock Release: Single

Power: 240v: 2.2kw 16 amps | 3 Phase: 3.5kw 9 amps

Lifting Height: 1900mm

Lifting Height with Adapters: 2060mm

Minimum Pad Height: 100mm

Overall Hoist Height: 3900mm

Overall Hoist Width: 3420mm

Drive through clearance: 2558mm

Width Between Columns: 2830mm

Lifting Time: 240v: 50-55sec | 3 Phase: 35-40sec

Arm Design: Asymmetric

Freight Dimensions:
L 3910mm W 570mm H 1020mm W 686KG

Warranty

We offer a comprehensive warranty on the EE-C9, covering 5 years on the structure and 1 year on electrical, mechanical, and hydraulic components.

This warranty includes both parts and labour, ensuring that your 2 post clear floor hoist remains reliable and fully supported, giving you peace of mind throughout its use.
