Measurements and colour are correct at the time of publishing, however are subject to change. If these are crucial to your facility or vehicle requirements it is essential for you to discuss your particular requirements with your Tufflift advisor prior to purchasing your new hoist.
Tufflift
4 Post Parking Hoist | 5 Ton Twin Platform
4 Post Parking Hoist | 5 Ton Twin Platform
SKU:TLD5.0TPL5.0M-A
Couldn't load pickup availability
The TLD5.0TPL5.0M is a versatile 5 ton twin platform 4 post parking hoist, designed for efficient vehicle storage in garages and workshops. With a 5000KG Safe Working Limit (2500Kg per platform), this hoist features manual lock release for ease of use and requires no compressor, making it a practical and reliable solution for vehicle maintenance and parking.
- 5000KG Safe Working Limit (2500Kg per side)
- Manual Lock Release (No compressor required)
- Durable Powder Coating
Includes:
- Wheel Chocks
- Hydraulic Oil
- End Plates
- Drip Trays
- Steel Tool Tray – H4D-6000
Options:
- Manual Sliding Jack – RJ35
- Infill Kit
- Aluminum Approach Ramp
Capacity: 5000kg
Minimum Concrete Requirement: 100mm
Recommended Ceiling Height: 3.7m
Power: 240v / 3.5kw 14.5amps
Clearance Under Platform: 2000mm
Overall Length (incl. ramps): 6201mm
Overall Length (excl. ramps): 5050mm
Overall Width (base plate): 5080mm
Width Between Columns: 4840mm
Freight Dimensions:
1. L 4270mm W 560mm H 730mm W 915Kg
2. L 5000mm W 560mm H 560mm W 1045Kg
We offer a comprehensive warranty on the TLD5.0TPL5.0M, covering 5 years on the structure and 1 year on electrical, mechanical, and hydraulic components.
This warranty includes both parts and labour, ensuring that your parking hoist remains reliable and fully supported, giving you peace of mind throughout its use.
Options
SPECIFICATIONS
-
100mm
Minimum Concrete Requirement
-
3.7m
Recommended Ceiling Height
-
240v / 3.5kw 14.5amps
Power Requirements
-
427 x 56 x 73cm 915kg
500 x 56 x 56cm 1045kgFreight Dimensions
